Kakaretso ea Tšebeletso
Thepa ena ea ultrasonic metal welder e sebetsa ka ho khetheha ho theheng maqhama a matla a metallurgical pakeng tsa li-tab tsa tšepe (nickel, aluminium) le liteishene tsa li-electrode tsa cylindrical cell. E fihlella sena ka taolo e nepahetseng ea phano ea matla (ka mokhoa oa ho hanyetsa kapa ka laser), ho netefatsa hore mocheso o fokolang-ka sebaka se amehileng le ho tšepahala ho ikhethang ha manonyeletso. Ts'ebetso ena e netefatsa khanyetso e tlase ea motlakase, matla a phahameng a tsitsipano, le ts'ebetso e ts'epahalang tlas'a vibrate, e leng bohlokoa bakeng sa lits'ebetso tsa betri ea matla. Ho sebetsa ka boiketsetso ho netefatsa boleng bo sa fetoheng-ho etsa thepa e phahameng.
Thepa Tse Amanang
Lisebelisoa tsa Parameters
Boholo ba Thepa:
Boholo ba jenereithara (Bolelele×Bophara×Bophahamo):480mm x365mm x202mm
Boholo ba Prow (Bolelele×Bophara×Boemo (ho tloha hodimo)::420mm x180mm x290mm
Boima ba 'mele: 62KG
Lisebelisoa tsohle tsa metering tsa lisebelisoa li nka likarolo tsa metric.
Lisebelisoa tsa Matla a Hlokahalang
Motlakase: 220VA ± 10%, Mohloli oa Moea: 0.4 ~ 0.6MPa; Mongobo: ＜48%, Mocheso: Ka tlase ho kapa ho lekana le likhato tse 45
Kopanyo ea Lisebelisoa:
Thepa e na le:
jenereithara ea ultrasonic, converter ea matla, manaka, likarolo tsa pneumatic le foreimi ea mochini, joalo-joalo.
Feletseng{{0}borokho bo phahameng{{1}sekotla sa motlakase;
Linaka tse entsoeng ka motsoako o mocha;
Litlhoko tse sebetsang tsa mochini oohle
Likarolo tsohle le likarolo li entsoe ka thepa ea tšepe.
Sebopeho sa module se tiisa lipalangoang tse bonolo.
Matla a ho khanna a sebetsang ke pneumatic drive.
Mohloli oa matla a sebetsang ke matla a mohato o le mong.
Litšenyehelo- tsa-Tšebeliso
Manaka a potlaka-a roala likarolo, ho tla fanoa ka tiisetso ea likhoeli tse 3 bakeng sa lenaka le ka holimo.
Sesebelisoa sa leoto se na le bophelo ba tšebeliso ea li-cycle tse limilione tse 1.5.
Motlakase o na le bophelo ba tšebeliso ea li-cycle tse limilione tse 1.5.
Litlhokomelo tsa Tšireletso
Ho tla tlisoa thepa feela e fihletseng li-criterations tsa lifeme.
Litlhokomelo bakeng sa tšebeliso:
1) Hang ha phello ea tjheseletsa e bontša ho sa tsitsane, ka kopo emisa ho sebetsa mochine, kapa ho seng joalo mosebedisi o lokela ho nahana ka tahlehelo kapa ho itšenyetsa;
2) Linaka li sebetsa ka potlako-ka kopo, hlahloba ho khojoa ha chelete ea tšepe ho tsona khafetsa, 'me u nkele tse senyehileng ka nako.
Litlhoko tsa Tekheniki
Matla a phahameng a tlhahiso ea NP1000 welder ke 1000VA, maqhubu a ultrasonic ke 20 KHZ ± 10%; litšoantšo tse latelang tsa Ⅱ,Ⅲ le Ⅳ ka ho latellana ke ponahalo ea mochine o feletseng, lenaka le ka holimo le lenaka le tlaase kapa anvil:
(Setšoantšo Ⅰ) Mokhoa oa nako, matla, matla le botebo tse bontšitsoeng ho
touch screen ea monna ea bohlale-tsamaiso ea taolo ea likhokahano tsa mochini
(Setšoantšo Ⅱ)Ponahalo ea mochini kaofela
Mokhoa oa ho Welding 1: Phello ea ho tjheseletsa ea 1 lera ea 0.1mm botenya ba Al strap e nang le 10-20 layers ea 0.012mm Al foils, sebaka se kopanetsoeng ke 5 * 20mm, mahlakore ka bobeli a lenaka a ka sebelisoa.
|
Che. |
Mokhoa oa ho cheselletsa |
Sebaka sa ho cheselletsa |
Papiso |
|
1 |
Letlapa la Nickel 0.1mm + foil ea koporo (8um) |
|
|
|
2 |
Theipi ea aluminium 0.1mm + foil ea aluminium (12um) |
|
|
|
3 |
Aluminium hlobolisa 0.1mm (sekoahelo poleiti atoloswa) + tab aluminium hlobolisa 0.1mm, kakaretso ea le dikarolo tse tharo tsa tjheseletsa |
|
|
Erection ea Thepa le Koetliso ea Basebetsi
Erection ea Lisebelisoa:
Morekisi o tla tsebisa baetsi ba thepa lintlha tse mabapi le ho hlophisoa ha lisebelisoa le likarolo tse hlokahalang le lisebelisoa.
Morekisi o tla tšehetsa erection hang-hang.
Koetliso ea basebetsi
Nakong ea ho lokisa, basebetsi ba Morekisi ba tla koetlisa opareitara hang-hang, litaba tsa koetliso li kenyelletsa ts'ebetso e tloaelehileng, tlhokomelo le kalafo ea tšohanyetso, joalo-joalo:
|
Litaba |
Ba koetlisitsoeng |
Qala ho tloha |
Course Length |
Litlhaloso |
|
Molao-motheo oa ts'ebetso, sebopeho sa lisebelisoa, ts'ebetso, ts'ebetso ea tšohanyetso le tlhokomelo, joalo-joalo |
Lienjiniere tsa motlakase le tsa mechini le li-operators, joalo-joalo. |
Nako ea ha thepa e felile ho lokisa liphoso. |
1 letsatsi |
Hlalosa ho latela buka ea litaelo le thepa e teng hang-hang. |
Ka mor'a tšebeletso ea thekiso
Morekisi o tla fana ka tiisetso ya selemo se 1-ho tloha ka letsatsi leo Moreki a fumaneng sesebediswa ka lona ntle le dikarolo- tsa ho roalwa kapele tse kang manaka, leoto le relay ya motlakase. Ho sa kenyeletsoe{4}}karohano ea kapele, bakeng sa likarolo tse ling tse sa sebetseng, Morekisi o tla ikarabella bakeng sa ho li nchafatsa ka bolokolohi haeba ho ka ba le lintho tseo e seng tsa batho.
Hang ha tiisetso e felile, moreki o lokela ho lefa bakeng sa tšebeletso ea tokiso le tlhokomelo e fanoeng ke Morekisi.
Lethathamo la likarolo
Likarolo tse kholo tsa NP1000 Smart ultrasonic metal welder (bongata ba mochini o le mong):
|
Lintho |
Bongata |
|
|
Prow |
Sebaka sa mosebetsi |
1 sengoathoana |
|
Likarolo tsa moea tse kang cylinder ea moea le valve ea makenete, joalo-joalo |
1 sete |
|
|
Foreimi ea pele |
1 sengoathoana |
|
|
Ultrasonic matla converter |
1 sengoathoana |
|
|
Matlafatsa |
1 sengoathoana |
|
|
Lenaka le ka hodimo |
1 sengoathoana |
|
|
Lenaka le ka tlase (kapa anvil) le setsi |
1 sete |
|
|
Motlakase tsamaiso |
Boto ea 'm'e |
1 sengoathoana |
|
Ultrasonic matla chip |
1 sengoathoana |
|
|
Ho fetola phepelo ea motlakase |
1 sengoathoana |
|
|
Automatic frequency tracking system |
1 sete |
|
|
Molaoli oa PLC |
1 sete |
Lenane la likarolo tse setseng (palo ea mochini o le mong)
|
Lethathamo la No. |
Lebitso la Sehlahiswa |
Mofuta |
Bongata |
|
1 |
Lenaka le ka hodimo |
20KHZ |
1 sengoathoana |
|
2 |
Lenaka le ka tlase (kapa anvil) |
20*20*20(mm) |
1 sengoathoana |
|
3 |
Wrench ea lehlakoreng le letona |
68-72 |
1 sengoathoana |
|
4 |
Allen senotlolo |
1 sete |
|
|
5 |
Buka ea litaelo |
1 sengoathoana |
|
|
6 |
Setifikeiti sa boleng |
1 sengoathoana |
|
|
7 |
Ka mor'a{{0}lengolo la thekiso |
1 sengoathoana |
|
|
9 |
Setšoantšo sa lithapo |
1 sengoathoana |
Bafani ba likarolo tse kholo le likarolo:
|
Lethathamo la No. |
Likarolo/Likaroloana |
Bafani ba thepa |
|
1 |
Likarolo tsa moea, valve ea makenete le moqomo oa metsi |
Taiwan AIRTAC |
|
2 |
Sephaphatha sa jenereithara |
Tektronix ea Jeremane |
|
3 |
PLC |
Delta ea Taiwan |
|
4 |
Die steel |
Jeremane e tsoang kantle ho naha 0 tšepe |
|
5 |
Lisebelisoa tsa motlakase holim'a boto ea potoloho |
TOSHIBA |
